LUX 3838 RGB+X Series Strip Features:
- 3838 RGB, RGBW, RGBCCT, all types colorful led strips, millions of mixing colors working with led controllers.
- 3 OZ FPC, original high quality 3M 9495LE tape, with special design strong package. LED with LM-80 Test approval.
- Energy-saving and environment-friendly.
- Customized service available, customized MOQ>500M, 3 Years Warranty.
| Model No | LED Density | Color | Lumen | Work Voltage | Ra |
Peak Power | Cutting Unit |
| A3828-D240-RGB+30K-V24-NWP | 240 leds/m | RGB+3000K | 1450Lm(W) | DC24V | >80 |
25 W/M | 12 LEDs 50mm |
| A3828-D240-RGB+40K-V24-NWP | RGB+4000K | ||||||
| A3828-D240-RGB+60K-V24-NWP | RGB+6000K |
|
LED Type |
3838 & 2835 SMD |
Input Voltage |
24V DC |
|
|
Color |
RGB+3000K/4000K/6000K |
Peak Power Per Meter |
25 w/m |
|
|
LED Density |
240 pcs/m |
Power Per Roll ( 5 meters) |
125 w/m |
|
|
Cuttable Segments |
12 LEDs / 50mm |
Lumen |
1450 Lm/m |
|
|
PCB Type/Color |
3 oz, White PCB |
Ra |
80+ |
|
|
PCB Width |
12 mm |
IP Grade |
IP20/IP54/IP65/IP67 |
|
|
Max Run Length |
5 m |
Warranty |
3 Years |
|
|
Reel Length |
5 m |
Certification |
UL CE BIS RoHS ERP |
| Model | LED Type | LED Qty | Color | Work Voltage | Power | Lumen |
Ra |
Cutting Unit | PCB Size |
| A3828-96-RGB+60K-V24-NWP |
SMD 3838 & 2835 |
96 | RGB+6000K | 24V DC | 12.8W/M | 460-500Lm (Only White Color) | >80 | 12 LEDs 125mm |
5000*8mm 3 OZ |
| A3828-96-RGB+40K-V24-NWP | RGB+4000K | ||||||||
| A3828-96-RGB+30K-V24-NWP | RGB+3000K | ||||||||
| A3828-D240-RGB+60K-V24-NWP | SMD 3838 & 2835 |
240 Double Lines |
RGB+6000K |
24V DC | 25W/M | 1450Lm(W) | >80 | 12 LEDs 50mm |
5000*12mm 3 OZ |
| A3828-D240-RGB+40K-V24-NWP | RGB+4000K |
||||||||
| A3828-D240-RGB+30K-V24-NWP | RGB+3000K |
