LUX-Ultra Long RGB CV&CC Strip Features:
- Made by Top 5050 RGB LEDs with latest technology.
- Designed to consistent the current and voltage of strip from the front to the end which have only 5% current differences.
- Max. working length up to 20M by one end powered.
- Thick 4 OZ FPC ,original 3M Brand tape, nice design package.
- Widely applied in commercial lighting, high cost-effective performance.
|
|
LED Type |
SMD 5050 |
Input Voltage |
24V DC |
|
|
Color |
Epistar High Brightness RGB |
Peak Power Per Meter |
12 w/m |
|
|
LED Density |
60 pcs/m |
Power Per Roll ( 5 meters) |
165 w/roll |
|
|
Cuttable Segments |
100mm (6 LEDs) |
Lumen |
--- |
|
|
PCB Type/Color |
4 oz, White PCB |
Ra |
--- |
|
|
PCB Width |
12 mm |
IP Grade |
IP20/IP67/IP68 |
|
|
Max Run Length |
20 m |
Warranty |
5 Years |
|
|
Reel Length |
20 m |
Certification |
UL CE BIS RoHS |
| Model | LED Type | LED Qty | Color | Work Voltage | Power | Max.Power per Roll | Cutting Unit | PCB Size |
| BPL5050-60-RGB-V24-NWP-P12-A4 | SMD5050 | 60pcs/m | RGB | 24V DC | 12W/M | 165w/roll | 6 LEDs 100mm | 20000*12mm 4 OZ |
| AL5050-60-RGB-V24-NWP-P12-A4 | SMD5050 | 60pcs/m | High Brightness RGB | 24V DC | 12W/M | 165w/roll | 6 LEDs 100mm | 20000*12mm 4 OZ |
| ALH5050-60-RGB-V24-NWP-P12-A4 | SMD5050 | 60pcs/m | Epistar High Brightness RGB | 24V DC | 12W/M | 165w/roll | 6 LEDs 100mm | 20000*12mm 4 OZ |
| HL5050-60-RGB-V24-NWP | SMD5050 | 60pcs/m | RGB | 24V DC | 14.4W/M | / | 5 LEDs 83mm | 20000*12mm 3 OZ |
| HLP5050-60-RGB-V24-NWP | SMD5050 | 60pcs/m | RGB | 24V DC | 14.4W/M | / | 5 LEDs 83mm | 20000*12mm 4 OZ |
| HL5050-60-RGB-V48-NWP | SMD5050 | 60pcs/m | RGB | 48V DC | 8.6W/M | 258'w/roll | 10 LEDs 167mm | 30000*12mm 4 OZ |
